2026 Complete Car Key Repair Book Online E-Book By MOE Diatronik

The Complete Car Key Repair Book from MOE Diatronik, an online e-book running to 523 pages on key composition, diagnostics and repair. Each key model gets a full PCB photo front and back with a colour coded component map, which is what makes it usable at the bench rather than only readable.

Specifications

• For each key model: full PCB photo (front & back), color-coded component map (power, buttons, inductors, capacitors, resistors) and a technical sheet (chip type, frequency, main IC, RF IC, crystal oscillator, working current).

Also stated by the supplier

• The most comprehensive car key reference ever written, composition, diagnostics, and full repair procedures for every key type on the market.
• Complete Car Key Repair Book
• WHAT'S INSIDE, 523 pages
• Resistors, inductors and capacitors in a car key
• 100+ Brands Covered, A to Z
• for Acura · Aftermarket Push-to-Start · for Aito · for Aiways · for Alfa Romeo · for Aston Martin · for Audi · for BAIC · for Baojun · for Bentley · for Bestune · for Bisu · for BMW · for Borgward · for Brilliance Auto · for Buick · for BYD · for Cadillac · for ChangAn · for ChangHe · for Chery · for Chevrolet · for Chrysler ·for Citroën · for CNHTC · for Denza · for DFAC · for Dodge · for DS · for Enovate · for Equus · for Ferrari · for Fiat · for Ford · for Geely · for Genesis · for GWM · for Haima · for Hanteng · for Harley · for Hawtai · for Holden · for Honda · for HongQi · for HongXing · for Hyundai · for Infiniti · JAC · Jaguar · Jeep · Jetour · JMC · Kia · Lamborghini · Land Rover · Landwind · Leapmotor · Lexus · Lifan · Lincoln · Luxgen · Lynk & Co · Maserati · Maxus · Mazda · McLaren · Mercedes-Benz · MG · MMC · NIO · Nissan · Opel · Peugeot · Porsche · Qoros · Renault · Roewe · Rolls-Royce · for Saab · for Smart · for Soueast · for Ssangyong · for Subaru · for Suzuki · for SWM · for Tata · for Tesla · for Toyota · for Trumpchi · for Vauxhall · for Venucia · for Volkswagen · for Volvo · for Voyah · for WM · for Wuling · for Xpeng · for Yema · for Zedriv · for ZhiDou · for Zotye
• Button comparison table
• 3D inductance & resistance reference

A colour coded component map per key model is the part you cannot get from a generic electronics book.
